This is a list of the most commonstill lifes in the Game of Life, specifically Catagolue's B3/S23/C1 census. The minimum known glider synthesis, as of April 2020, of each still life is also displayed. The 'approximate relative frequency' column gives an estimate of the proportion of all randomly-occurring still lifes that will be of the given type.
Thirty-five years ago Dallas—and the country—was gripped by the tragic story of John McClamrock, a high school football player paralyzed during a violent tackle. But after the newspapers moved on, another story was quietly unfolding, one of courage, perseverance, and a mother’s fierce love. C ompared with the glistening two. In Still Life, you play the role of Victoria McPherson, a young FBI agent who's investigating a serial murder case. Set in modern Chicago and late-1920s Prague, the game lets you investigate the.
This table only includes strict still lifes and thus does not count objects like honey farms.
| Rank | Pattern | # of cells | Glider cost | Approximate relative frequency (out of 1.00) |
|---|---|---|---|---|
| 1 | Block | 4 | 2 | 0.496 |
| 2 | Beehive | 6 | 2 | 0.263 |
| 3 | Loaf | 7 | 2 | 0.0776 |
| 4 | Boat | 5 | 2 | 0.0717 |
| 5 | Ship | 6 | 3 | 0.0494 |
| 6 | Tub | 4 | 3 | 0.0156 |
| 7 | Pond | 8 | 2 | 0.0152 |
| 8 | Long boat | 7 | 3 | 0.00503 |
| 9 | Ship-tie | 12 | 4 | 0.00255 |
| 10 | Barge | 6 | 3 | 0.00106 |
| 11 | Half-bakery | 14 | 3 | 0.000865 |
| 12 | Mango | 8 | 3 | 0.000389 |
| 13 | Eater 1 | 7 | 2 | 0.000251 |
| 14 | Long barge | 8 | 3 | 0.000141 |
| 15 | Aircraft carrier | 6 | 4 | 0.000122 |
| 16 | Paperclip | 14 | 3 | 0.0000709 |
| 17 | Long ship | 8 | 4 | 0.0000483 |
| 18 | Integral sign | 9 | 4 | 0.0000444 |
| 19 | Shillelagh | 8 | 4 | 0.0000383 |
| 20 | Boat-tie | 10 | 4 | 0.0000375 |
| 21 | Snake | 6 | 4 | 0.0000336 |
| 22 | Big S | 14 | 4 | 0.0000335 |
| 23 | Bi-pond | 16 | 3 | 0.0000292 |
| 24 | Trans-boat with tail | 9 | 4 | 0.0000160 |
| 25 | Boat tie ship | 11 | 4 | 0.0000133 |
| 26 | Hat | 9 | 3 | 0.0000126 |
| 27 | Very long ship | 10 | 4 | 0.0000103 |
| 28 | Very long boat | 9 | 3 | 0.00000922 |
| 29 | Tub with tail | 8 | 4 | 0.00000870 |
| 30 | Table and table | 12 | 4 | 0.00000651 |
| 31 | Dead spark coil | 18 | 4 | 0.00000615 |
| 32 | Canoe | 8 | 4 | 0.00000540 |
| 33 | Cis-mirrored R-bee | 14 | 4 | 0.00000398 |
| 34 | Moose antlers | 15 | 4 | 0.00000358 |
| 35 | Beehive on dock | 16 | 4 | 0.00000292 |
| 36 | Block on table | 10 | 4 | 0.00000291 |
| 37 | Block on dock | 14 | 4 | 0.00000265 |
| 38 | Scorpion | 16 | 4 | 0.00000213 |
| 39 | Beehive with tail | 10 | 4 | 0.00000176 |
| 40 | Twin hat | 17 | 4 | 0.00000168 |
| 41 | Loop | 10 | 4 | 0.00000144 |
| 42 | Long snake | 7 | 4 | 0.00000142 |
| 43 | Fourteener | 14 | 4 | 0.00000140 |
| 44 | Bookends | 14 | 4 | 0.00000114 |
| 45 | Cis-boat with tail | 9 | 4 | 9.225×10-7 |
| 46 | Cis-rotated hook | 14 | 4 | 9.084×10-7 |
| 47 | Elevener | 11 | 4 | 8.872×10-7 |
| 48 | Mirrored dock | 20 | 4 | 8.178×10-7 |
| 49 | Block on cap | 12 | 4 | 7.902×10-7 |
| 50 | Trans-loaf with tail | 11 | 4 | 7.689×10-7 |
| 51 | Cis-shillelagh | 10 | 4 | 7.571×10-7 |
| 52 | Trans-mirrored R-bee | 14 | 4 | 7.350×10-7 |
| 53 | Trans-block on long hook | 12 | 4 | 6.897×10-7 |
| 54 | Prodigal | 10 | 4 | 6.219×10-7 |
| 55 | Broken snake | 10 | 4 | 5.623×10-7 |
| 56 | Trans-hook and R-bee | 14 | 4 | 5.201×10-7 |
| 57 | Eater head siamese eater tail | 12 | 4 | 5.070×10-7 |
| 58 | Block and two tails | 12 | 4 | 5.063×10-7 |
| 59 | Cis-boat on dock | 15 | 4 | 5.049×10-7 |
| 60 | Cis-block on long hook | 12 | 4 | 4.736×10-7 |
| 61 | Very long snake | 8 | 4 | 4.687×10-7 |
| 62 | Boat with long tail | 10 | 4 | 4.358×10-7 |
| 63 | Long shillelagh | 9 | 4 | 4.188×10-7 |
| 64 | Beehive at loaf | 13 | 4 | 4.161×10-7 |
| 65 | Trans-R-bee and R-loaf | 15 | 4 | 3.489×10-7 |
| 66 | Long integral | 10 | 4 | 3.356×10-7 |
| 67 | Tub with long tail | 9 | 4 | 3.340×10-7 |
| 68 | Cis-hook and R-bee | 14 | 4 | 3.336×10-7 |
| 69 | Hook with tail | 8 | 4 | 3.328×10-7 |
| 70 | Loaf siamese loaf | 11 | 4 | 3.260×10-7 |
| 71 | Long canoe | 9 | 4 | 2.674×10-7 |
| 72 | 11 loop | 11 | 4 | 2.633×10-7 |
| 73 | Ortho-loaf on table | 13 | 4 | 2.625×10-7 |
| 74 | Cis-loaf with tail | 11 | 4 | 2.614×10-7 |
| 75 | Symmetric scorpion | 16 | 4 | 2.612×10-7 |
| 76 | Claw with tail | 10 | 4 | 2.508×10-7 |
| 77 | Bee hat | 15 | 4 | 2.380×10-7 |
| 78 | Up dove on dove | 18 | 4 | 2.342×10-7 |
| 79 | Trans-rotated R-bee | 14 | 4 | 2.335×10-7 |
| 80 | Up wing on wing | 16 | 4 | 2.284×10-7 |
| 81 | R-bee and snake | 13 | 4 | 2.090×10-7 |
| 82 | Boat tie eater tail | 12 | 4 | 1.966×10-7 |
| 83 | Snorkel loop | 12 | 4 | 1.880×10-7 |
| 84 | Beehive on table | 12 | 4 | 1.859×10-7 |
| 85 | Cis-boat on table | 11 | 4 | 1.812×10-7 |
| 86 | Trans-barge with tail | 10 | 4 | 1.685×10-7 |
| 87 | Trans-boat on dock | 15 | 4 | 1.580×10-7 |
| 88 | Beehive on cap | 14 | 4 | 1.561×10-7 |
| 89 | Beehive at beehive | 12 | 4 | 1.558×10-7 |
| 90 | Ship on long boat | 13 | 5 | 1.548×10-7 |
| 91 | Cis-boat and cap | 13 | 4 | 1.494×10-7 |
| 92 | Beehive bend tail | 12 | 4 | 1.488×10-7 |
| 93 | Trans-boat with nine | 11 | 4 | 1.450×10-7 |
| 94 | 15-bent-paperclip | 15 | 4 | 1.417×10-7 |
| 95 | Beehive with nine | 12 | 4 | 1.259×10-7 |
| 96 | Very long barge | 10 | 5 | 1.221×10-7 |
| 97 | Trans-long boat with tail | 11 | 4 | 1.181×10-7 |
| 98 | Cis-R-bee and R-loaf | 15 | 4 | 1.101×10-7 |
| 99 | Hungry hat | 11 | 4 | 1.051×10-7 |
| 100 | Trans-boat on table | 11 | 4 | 1.015×10-7 |
| 101 | Cis-boat with nine | 11 | 5 | 1.010×10-7 |
| 102 | xs13_321fgkc | 13 | 4 | 9.659×10-8 |
| 103 | Loaf back tie loaf | 14 | 4 | 9.069×10-8 |
| 104 | Loaf tie eater with tail | 18 | 4 | 8.909×10-8 |
| 105 | Mango with block on dock | 19 | 4 | 8.579×10-8 |
| 106 | Trans-R-bee and R-mango | 16 | 4 | 8.256×10-8 |
| 107 | Rotated C | 18 | 4 | 8.005×10-8 |
| 108 | Boat tie long boat | 12 | 4 | 7.985×10-8 |
| 109 | Cis-mirrored longhook | 16 | 4 | 7.914×10-8 |
| 110 | xs19_69bo7pic | 19 | 4 | 7.615×10-8 |
| 111 | Trans-ship and dock | 16 | 4 | 7.532×10-8 |
| 112 | Trans-mango with tail | 12 | 4 | 7.376×10-8 |
| 113 | 13-boat wrap eater | 13 | 4 | 7.193×10-8 |
| 114 | Bi-loaf 2 | 14 | 4 | 7.080×10-8 |
| 115 | Para-R-bee on loaf | 14 | 4 | 6.964×10-8 |
| 116 | Inverted double claw | 12 | 5 | 6.933×10-8 |
| 117 | Big S with tub | 15 | 4 | 6.859×10-8 |
| 118 | xs17_2ege1t6zx11 | 17 | 4 | 6.634×10-8 |
| 119 | ?13-head | 13 | 4 | 6.632×10-8 |
| 120 | R-bee on beehive | 13 | 4 | 6.327×10-8 |
| 121 | Cis-hook and R-loaf | 15 | 4 | 6.250×10-8 |
| 122 | Boat with hooked tail | 11 | 4 | 5.985×10-8 |
| 123 | Longhook and dock | 18 | 5 | 5.904×10-8 |
| 124 | Pond on R-loaf | 16 | 4 | 5.844×10-8 |
| 125 | Carrier siamese carrier | 10 | 4 | 5.832×10-8 |
| 126 | Very long shillelagh | 10 | 4 | 5.771×10-8 |
| 127 | Pond and cap | 16 | 4 | 5.769×10-8 |
| 128 | House siamese shillelagh | 13 | 5 | 5.731×10-8 |
| 129 | Long hook with tail | 9 | 5 | 5.706×10-8 |
| 130 | xs18_0mmge96z1221 | 18 | 6 | 5.678×10-8 |
| 131 | Snake with feather | 11 | 4 | 5.676×10-8 |
| 132 | Trans-hook and R-loaf | 15 | 4 | 5.528×10-8 |
| 133 | Carrier with feather | 11 | 4 | 5.433×10-8 |
| 134 | Barge siamese loaf | 10 | 5 | 5.372×10-8 |
| 135 | Carrier siamese dock | 14 | 4 | 5.350×10-8 |
| 136 | Cis-mirrored offset hooks | 14 | 4 | 5.332×10-8 |
| 137 | Long^3 boat | 11 | 4 | 5.324×10-8 |
| 138 | Cis-mirrored worm | 22 | 4 | 5.252×10-8 |
| 139 | Cis-beehive and longhook | 14 | 4 | 5.104×10-8 |
| 140 | xs14_g8id96z121 | 14 | 5 | 4.814×10-8 |
| 141 | ?22-trans-mirrored long | 22 | 6 | 4.772×10-8 |
| 142 | Cis-barge with tail | 10 | 4 | 4.704×10-8 |
| 143 | Krake | 13 | 4 | 4.509×10-8 |
| 144 | Ship tie snake | 12 | 5 | 4.506×10-8 |
| 145 | ?14-beehive with long bend tail | 14 | 4 | 4.495×10-8 |
| 146 | Pond on dock | 18 | 4 | 4.285×10-8 |
| 147 | 12-loop | 12 | 4 | 4.217×10-8 |
| 148 | xs13_354mp3 | 13 | 4 | 4.137×10-8 |
| 149 | O quad-loaf | 28 | 6 | 4.003×10-8 |
| 150 | Sidewalk | 14 | 4 | 3.986×10-8 |
| 151 | xs14_2egu156 | 14 | 4 | 3.857×10-8 |
| 152 | xs13_08ka96z321 | 13 | 4 | 3.788×10-8 |
| 153 | Para-hook and R-havoc | 16 | 4 | 3.707×10-8 |
See also
A still life (or stable pattern) is a pattern that does not change from one generation to the next, and thus may be thought of as an oscillator with period 1. Still lifes are sometimes assumed to be finite and non-empty. The two main subgroups of still lifes are strict still lifes and pseudo still lifes. In some contexts, the term 'still life' may refer to stable objects rather than stable patterns in general, or strict still lifes rather than stable objects in general.
Strict still lifes
A strict still life is a still life that is either connected (i.e., has only one island), or is such that removing one or more its islands destroys the stability of the pattern. For example, beehive with tail is a strict still life because it is connected, and table on table is a strict still life because neither of the tables are stable by themselves.
Beehive is a strict still life because it is connected. | Beehive with tail is a strict still life because it is connected, even though it contains a smaller still life. | Table on table is a strict still life because neither table is stable without the other. |
Pseudo still lifes
A pseudo still life consists of two or more islands which can be partitioned (either individually or as sets) into non-interacting subpatterns which are by themselves each still lifes. Furthermore, there must be at least one dead cell that has more than three alive neighbours in the overall pattern but has less than three alive neighbours in the subpatterns. This final restriction removes patterns such as bakery, blockade and fleet from consideration, as the islands are not 'almost touching'.
Note that a pattern may have multiple disconnected components and still be a strict (as opposed to pseudo) still life if the disconnected components are dependent on each other for stability (for example, table on table above). Some pseudo still lifes have also been found by Gabriel Nivasch that can be partitioned into a minimum of three and four stable subpatterns, respectively, as in the second and third images below.[1] The stable subpatterns themselves may be either strict or pseudo still lifes. It is not possible to construct a pseudo still life that can be partitioned into a minimum of greater than four stable subpatterns because of the Four Color Theorem.[1]
Bi-block is a pseudo still life because each block is stable by itself. | The triple pseudo still life, which can be partitioned into three to five independent stable subpatterns, but not two. RLE:here | The quad pseudo still life, which can be partitioned into four still lifes, but not two or three. RLE:here |
It has been shown that it is possible to determine whether a still life pattern is a strict still life or a pseudo still life in polynomial time by searching for cycles in an associated skew-symmetric graph.[2][3]
Constellations
A (stable) constellation is a still life that is composed of two or more non-interacting objects. This contrasts with pseudo and quasi still lifes, in which the objects in question must interact. Compare for instance the bi-block and blockade:
Bi-block is a pseudo still life because the two blocks interact: the two dead cells between them are influenced by both. | Blockade is a constellation because the four blocks do not interact in any way. |
Certain unstable (e.g. oscillating) patterns are sometimes also referred to as constellations. The term 'stable constellation' is used to refer specifically to still life constellations.
Quasi still lifes
A stable constellation in which the constituent objects share dead cells, but where all cells that used to remain dead from under-population in the overall pattern still do so in the constituent objects, is called a quasi still life. In Conway's Life, this occurs when objects are diagonally adjacent (e.g. two blocks sharing a single diagonal neighbor), or when single protruding cells in two objects such as tubs share multiple neighbors.
Two blocks sharing a single diagonal neighbor, marked in green; this cell is dead from underpopulation, and remains so after separation. |
The term 'quasi still life' is due to Mark Niemiec.
Enumerating still lifes
Still Life Game Pc
The number of strict and pseudo still lifes that exist for a given number of cells has been enumerated up to 34, and the number of quasi still lifes for a given number of cells up to 22.
Still Life Gameplay
- The values in the strict still life table below were originally computed by John Conway (4-7 cells), Robert Wainwright (8-10 cells), David Buckingham (11-13 cells), Peter Raynham (14 cells), Mark Niemiec (15-24 cells), Simon Ekström (25-28 cells),[4][5][6] Simon Ekström and 'Apple Bottom' (29-30 cells),[7] and Nathaniel Johnston (31-34 cells).[8][9][10][11]
- The values in the pseudo still life table were enumerated by Mark Niemiec (1-24 cells), Simon Ekström (25-28 cells),[4][5][6] Simon Ekström and 'Apple Bottom' (29-30 cells),[7] and Nathaniel Johnston (31-34 cells).[8][9][10][11]
- The values in the quasi still life table below were originally computed by Mark Niemiec (8-20 cells) and Simon Ekström (21-22 cells).[12]
| Live cells | Strict still lifes | Pseudo still lifes | Quasi still lifes | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Count (A019473) | Examples | List | Count (A056613) | Examples | List | Count | Examples | List | |
| 1 | 0 | 0 | 0 | ||||||
| 2 | 0 | 0 | 0 | ||||||
| 3 | 0 | 0 | 0 | ||||||
| 4 | 2 | block, tub | Full list | 0 | 0 | ||||
| 5 | 1 | boat | Full list | 0 | 0 | ||||
| 6 | 5 | beehive, ship | Full list | 0 | 0 | ||||
| 7 | 4 | eater 1, loaf | Full list | 0 | 0 | ||||
| 8 | 9 | canoe, pond | Full list | 1 | bi-block | Full list | 6 | ||
| 9 | 10 | hat, integral sign | Full list | 1 | block on boat | Full list | 13 | ||
| 10 | 25 | boat-tie, loop | Full list | 7 | bi-boat | Partial list | 57 | ||
| 11 | 46 | elevener | Full list | 16 | 141 | ||||
| 12 | 121 | honeycomb, table on table | Full list | 55 | 465 | ||||
| 13 | 240 | sesquihat | Partial list | 110 | 1,224 | ||||
| 14 | 619 | fourteener, paperclip | Partial list | 279 | 3,956 | ||||
| 15 | 1,353 | moose antlers | Partial list | 620 | 11,599 | ||||
| 16 | 3,286 | bi-cap, scorpion | Partial list | 1,645 | pond on pond | Partial list | 36,538 | ||
| 17 | 7,773 | twin hat | Partial list | 4,067 | 107,415 | ||||
| 18 | 19,044 | dead spark coil | Partial list | 10,843 | 327,250 | ||||
| 19 | 45,759 | eater 2 | Partial list | 27,250 | 972,040 | ||||
| 20 | 112,243 | spiral | Partial list | 70,637 | 2,957,488 | ||||
| 21 | 273,188 | tri-loaf 2 | Partial list | 179,011 | 8,879,327 | ||||
| 22 | 672,172 | cis-mirrored worm | Partial list | 462,086 | 26,943,317 | ||||
| 23 | 1,646,147 | 1,184,882 | |||||||
| 24 | 4,051,732 | lake 2 | Partial list | 3,069,135 | |||||
| 25 | 9,971,377 | 7,906,676 | |||||||
| 26 | 24,619,307 | Mickey Mouse | Partial list | 20,463,274 | |||||
| 27 | 60,823,008 | hat siamese vase | Partial list | 52,816,265 | |||||
| 28 | 150,613,157 | O quad-loaf | Partial list | 136,655,095 | |||||
| 29 | 373,188,952 | xs29_cc0s2ticz330fgkc | Partial list | 353,198,379 | |||||
| 30 | 926,068,847 | Clips | Partial list | 914,075,620 | |||||
| 31 | 2,299,616,637 | Aries betwixt two blocks | Partial list | 2,364,815,358 | |||||
| 32 | 5,716,948,683 | Inflected 30-great sym | Partial list | 6,123,084,116 | triple pseudo still life | Partial list | |||
| 33 | 14,223,867,298 | 15,851,861,075 | |||||||
| 34 | 35,422,864,104 | Partial list | 41,058,173,683 | quad pseudo still life | Partial list | ||||
As the number of bits increases, these counts increase exponentially; the rate for strict still lifes is about O(2.46n), while for pseudo still lifes it is around O(2.56n), and approximately O(3.04n) for quasi still lifes.
See also
References
- ↑ 1.01.1Nivasch, Gabriel (July, 2001). 'Still lifes'. Retrieved on March 23, 2016.
- ↑Cook, Matthew (2003). 'Still life theory'. New Constructions in Cellular Automata: 93–118, Santa Fe Institute Studies in the Sciences of Complexity, Oxford University Press.
- ↑Cook, Matthew. 'Still Life'. Mathematical Sciences Research Institute.
- ↑ 4.04.1Simon Ekström (January 2, 2017). Re: Enumerating Still Lifes (in C) (discussion thread) at the ConwayLife.com forums
- ↑ 5.05.1Simon Ekström (January 3, 2017). Re: Enumerating Still Lifes (in C) (discussion thread) at the ConwayLife.com forums
- ↑ 6.06.1Simon Ekström (January 7, 2017). Re: Enumerating Still Lifes (in C) (discussion thread) at the ConwayLife.com forums
- ↑ 7.07.1Simon Ekström (January 14, 2017). Re: Enumerating Still Lifes (in C) (discussion thread) at the ConwayLife.com forums
- ↑ 8.08.1Nathaniel Johnston (March 27, 2017). Re: Enumerating Still Lifes (in C) (discussion thread) at the ConwayLife.com forums
- ↑ 9.09.1Nathaniel Johnston (May 25, 2017). Re: Enumerating Still Lifes (in C) (discussion thread) at the ConwayLife.com forums
- ↑ 10.010.1Nathaniel Johnston (April 5, 2019). Re: Enumerating Still Lifes (in C) (discussion thread) at the ConwayLife.com forums
- ↑ 11.011.1Nathaniel Johnston (January 9, 2020). Re: Enumerating Still Lifes (in C) (discussion thread) at the ConwayLife.com forums
- ↑Mark Niemiec (January 15, 2017). Re: Enumerating Still Lifes (in C) (discussion thread) at the ConwayLife.com forums
External links
- Still life at Wikipedia
- Still life at the Life Lexicon
- Pseudo still life at the Life Lexicon
- Quasi still life at the Life Lexicon
- Life Object Counts at Mark D. Niemiec's Life Page
